| Camera Type | Bullet IP Camera | |||
| System | Embedded RTOS design | |||
| Camera | Effective Pixels | 8.0 Mega Pixels(4K) | 5.0 Megapixels | 5.0 Mega Pixels |
| Main stream:3840*2160; | Main stream:2592*1944; | Main stream:2592*1944; | ||
| 2592*1944 | 4MP;3MP | 2592*1520 | ||
| Sub stream:704*576 | Sub stream:704*576 | Sub stream:704*576 | ||
| Frames Rates | PAL:18fps(3840*2160); | PAL:25fps(2592*1944) | PAL:18fps(2592*1944)/ | |
| 25fps(2592*1944) | 25fps(2592*1520) | |||
| NTSC:18fps(3840*2160); | NTSC:30fps(2592*1944) | NSTC:18fps(2592*1944)/ | ||
| 30fps(2592*1944) | 30fps(2592*1520) | |||
| Image Sensor | 1/2" OV OS08A10 CMOS Sensor | 1/1.8" SONY Exmor IMX178 CMOS Sensor | 1/2.5" PS5510 CMOS Sensor | |
| 8 megapixel resolution (3864H*2202V) | 6 Megapixel resolution | 5 megapixel resolution | ||
| (3072H*2048V) | ||||
| DSP | Dual core 32-bit DSP | Dual core 32-bit DSP | Dual core 32-bit DSP | |
| (HI3516A) | (Hi3516A) | (Hi3516D) | ||
| Min. Illumination | Color 0.001Lux@F1.2 | Color 0.01Lux@F1.2 | Color 0.01Lux@F1.2 | |
| B/W 0.0001 Lux@F1.2 | B/W 0.001 Lux@F1.2 | B/W 0.01 Lux@F1.2 | ||
| Adjust Parameters | DWDR,BLC,DNR,AE,AGC,D&N,Mirror,Flip,etc. | |||
| Video | Compression | H.265/H.264 Main profile | H.265/H.264 Main profile | H.265/H.264 Main profile |
| Stream | support dual stream,AVI format | support dual stream,AVI format | support dual stream,AVI format | |
| Bit Rate | support 0.1M ~8Mpbs bit rate adjustable | support 0.1M ~8Mpbs bit rate adjustable | support 0.1M ~8Mpbs bit rate adjustable | |
| Frame Rates | support 1~30fps adjust | support 1~30fps adjust | support 1~30fps adjust | |
| Audio | Input and output | 1ch input( micphone),1ch output( Speaker&micphone) Optional | ||
| Compression | G.711 compression,support two-way audio intercom,support audio and video synchronized output | |||
| Alarm | Types | Motion Detection,Video Blind,Video Loss | ||
| Network | WEB Browser | Support WEB remote config( IE,Safari,Google Chrome,Firefox etc.) | ||
| Smart Phone | mobile remote Monitoring (iPhone,Android,....) | |||
| CMS Software | Uniform CMS Software(multiple devices management system) | |||
| Cloud P2P | MYEYE platform and other program,Offer SDK | |||
| Network | 1*RJ45,10/100M,Support RTSP/FTP/PPPOE/DHCP/DDNS/NTP/UPnP/SMTP | |||
| ONVIF | Support (ONVIF 2.4) | |||
| POE | Support(optional) | |||
| WIFI | N/A | |||
| General | Language | 20 kinds of languages such as English,Finnish,French,German,Greek,Italian,Japanese,Polish,Portuguese,Russian,Spanish,Thai,S-Chinese,T-Chinese and Turkish | ||
| IR Cut Filter | Set of double light switch IR-CUT filter | |||
| Lens Mount | Varifocal Lens 3.6-11mm | |||
| Infrared Luminary | 4pcs Array IR LED | |||
| Infrared Wavelength | 850nm | |||
| Illuminate Distance | 40m | |||
| Waterproof Criterion | IP66 | |||
| I/O Connector | 1*DC Connector,1*RJ45(10/100M Network) | |||
| Supplied Voltage | DC12V/PoE(802.3af/820.3at) | |||
| Power Consumption | IR On:600mA max.,IR Off:Less than 200mA | |||
| Working Environment | -10°C~+60°C,10%~90% ( Built in Heater being optional added for enviroment lower than -20°) | |||
