| Model | JYD-V7344HY-2.0MP | JYD-V7344HY-4.0MP | JYD-V7344HY-5.0MP | ||||
| Image Sensor | 1/2.8" SONY CMOS,2.0 Megapixels,IR-CUT | 1/3" OV 4.0 Megapixel CMOS Sensor | 1/3" OV 5.0 Megapixel CMOS Sensor | ||||
| Effective Pixels | 1920*1080 | 2592*1520 | 2592*1944 | ||||
| Video Frame Rate | PAL: 25fps NTSC: 30fps | ||||||
| Electronic Shutter | Auto: PAL 1/50-1/100, 000Sec;NTSC 1/60-1/100, 000Sec | ||||||
| Synchronization | Internal | ||||||
| Mini. Illumination | 0.001Lux/F1.2(AGC ON), 0Lux IR on | ||||||
| Video Output | 1-channel BNC HDAHD high definition video output | ||||||
| Camera Features | |||||||
| Max. IR LEDs Length | >25M | ||||||
| IR LEDs | Built-in 30 pieces IR-LED | ||||||
| Day/Night | Auto(ICR) / Color / B/W | ||||||
| Noise Reduction | 2D | ||||||
| Lens | |||||||
| Varifocal 4-9mm | Varifocal 2.8-12mm (2 Mega Pixel) | ||||||
| Lens Type | Board Lens | ||||||
| General | |||||||
| Transmission Distance | Over 500m via 75-3 coaxial cable | ||||||
| Power Supply | DC12V±10% | ||||||
| Ingress Protection | IP66 | ||||||
| Power Consumption | Max 4W | ||||||
| Working Environment | -30°C~+60°C / Less than 95%RH | ||||||
