Feature:
*1.0MP FHD Mini AHD Camera
*3.6MM Lens
*Digital Microphone Supported
*Signal System: PAL/NTSC
*Power Supply: DC 12V
Specification:
| Model: | MINI-05 |
| Sensor: | Cmos Image Sensor |
| Electronic Shutter: | PAL:1/50~1/100000s; |
| NTSC:1/60~1/100000s; | |
| Focus: | Manually |
| Signal System: | PAL/NTSC |
| Resolution: | 1280*960 |
| Minimun Illumination: | 0.1 Lux |
| Max Transmission Distance: | Common 75-3 lines can be up to 500m |
| Lens Parameter: | 3.6MM Lens,other can be optional |
| Voltage: | DC12V |
| IR-CUT Filter(IR Filter): | Default at 650nm,custom options at 850 or 940nm |
| IR Illumination: | Not Support,can be customized |
| Night Vision: | Not Support,can be customized |
| S/N Radio: | More than 52dB(AGC Off) |
| Gamma: | 0.45/1.0 |
| Exposure: | Auto |
| OSD: | Yes |
| Sync.System: | Internal |
| Video Output: | 1xBNC |
| Audio: | Digital Mircophone |
| Power Supply: | DC 12V |
| Dimension: | 15x15mm |
| Operating Temperature: | -20 to 70°C |
