IPH9925-4G/20X
| Model | Sensor | Speed | function |
| IPH9925-4G/20X | HI3516EV300+IMX335 | Medium speed(60degree/S) | Auto tracking ,Support SD+ 4G (wifi optional) |
1.support level 360 degrees without limit rotation, vertical 90 degree
2. built-in high sensitivity microphone, pickup range of 100 square meters. And support speaker output
3.support infrared light automatic / manual control, and support infrared light brightness adjustment
4. support photosensitive resistance sensitivity adjustment.
5. support level 360-degree scanning, and support scanning speed adjustment
6. support 256 presets
7.support 3 groups of cruise, and support cruise speed adjustment and cruise point dwell time adjustment.
8. support limit scan, and support scan speed adjustment.
9.support a Home position, and support time settings
10.support idle action
11.support the focus mode of three different application scenarios.
12.support temperature control mode (requires additional thermostat)
13.Supports dual light source mode. White light is on when object moves, and image is color.
20x zoom Camera
1.support 18x optical zoom, lens focal length: 4.7-94 mm
2.HI3516EV300+IMX335 ,5MP(2560*1920)，20fps，4MP(2560x1440)25fps
used SONY star-level CMOS chip IMX307/335
HI3516EV300+IMX335 Rate: Support 5MP (2560*1920), 20 frame rate, 4MP (2560x1440) 25 frame rate
3.support H.264/265/265+ compression algorithm.
4. support multiple network protocols TCP / IP, HTTP, TCP, ICMP, UDP, ARP, IGMP, SMTP, FTP, DHCP, DNS, DDNS, NTP, UPNP, RTSP, etc
5.support P2P connection
6.support for audible alarms, and can customize the alarm sound
7. support P2P alarm push
8.support SD card storage, maximum support 128GB (only for devices that support SD card + WIFI version)
9.support SD card main stream capture (only for devices that support SD card + WIFI version)
10.support imges FTP upload
11.support ONVIF Protocol
12.support RTSP push stream
13.support humanoid recognition, and support humanoid recognition alarm linkage :video, capture, FTP upload, voice alarm, APP alarm push, alarm video. And support 4 personal shape recognition area (can be used for regional intrusion settings)
14.support SMD (including Smart PQ, Low Bitrate, humanoid detection)
15.support alarm input and output (optional)
16.support DDNS dynamic domain name resolution
17.support two-way language intercom
Specification Sheet
| 4.5 Inch Auto tracking PTZ camera | |
| Operating system | embedded LINUX |
| Main processor | HiSilicon 3516EV300 |
| Image Sensor | SONY IMX 335 (5MP IP Camera) |
| Day and night mode | Support |
| Compression standard | |
| Compression standard | H.265+,H.265，H.264 Video compression algorithm supports H.265+,H.265, H.264 |
| Audio compression algorithm | G.711U |
| Compressed transport stream | 256Kbps-12288Kbps, can be customized, default 1536Kbps |
| Images | |
| Maximum image size | 5MP (2560x1920) |
| Code stream/frame rate | Main stream: 5MP 20fps,4MP 25fps,3MP,2MP 25fps |
| Substream：448P（800*448）25fps，D1 25fps，CIF 25fps | |
| Character overlay | Support OSD Channel name, time and date information overlay |
| Image settings | Brightness, contrast, saturation, exposure, up and down reverse, left and right mirroring adjustable |
| Network Function | |
| Storage function | Supports up to 128G Micro SD card storage. supports alarm and scheduled video storage |
| Motion detection | Four independent detection areas can be set (sensitivity: High ,Medium ,Low can be set) |
| Humanoid detection | support the detection of up to 3 humanoid targets, can set four independent detection areas, and support humanoid detection alarm trigger (sensitivity:high ,medium and low can be set) |
| Alarm linkage | alarm sends the picture to the specified mailbox; the alarm uploads the picture is uploaded to the FTP server，SD card record, SD card capture，APP Messages push,audio output; |
| Network Protocol | Supports TCP/IP, HTTP, TCP, ICMP, UDP, ARP, IGMP, SMTP, FTP, DHCP, DNS, DDNS, NTP, UPNP, RTSP |
| Interface | |
| Audio input | Build in MIC |
| Audio output | Support |
| LANinterface | Wifi wireless ,RJ45 10Base-T/100Base-TX, WIFI/802.11b/g/n wireless |
| PTZ speed dome | |
| Infrared illumination distance | 80M |
| LENS | 18x optical zoom,4.7-94mm |
| waterproof level | IP66 |
| Rotation speed | 120 degree/S (High speed) 60 degree/S (High speed) |
| Working temperature | Ambient temperature ：-40℃ ～ +85℃ |
| Power adapter | DC12V 3A |
| Working Humidity | -10-95% |
